Product Description
| Model: | IF-USB-CC-2-45-3A-45W |
| Product Name: | USB-C Socket Module |
| Support Agreement: | Type-C:Support PD protocol |
| Output Current And Voltage: |
Type-C:5V 3A、9V 3A、12V 3A、15V 3A、20V 2.25A Type-C+Type-C:5V 3.1A |
| DC out Power: | 45W max |
| No-Load Power Consumption: | 0.1W max |
| Input Voltage: | 100-240V/AC 50~60HZ |
| Insulating Material: | Fire Retardant PC |
| Insulation Resistance: | Between input and output 500VDC/2MΩ |
| Working Temperature And Humidity: | -10℃~+40℃ 20%~90%RH |
| Withstand Voltage Strength: | Between input and output ≥3KV/AC 1min |
